Description
| Overall dimension | 8000*2500*3200mm | ||
| GVW | 15800kg | ||
| Curb weight | 7805kg | ||
| Traction type | 6*6, left hand drive | ||
| Chassis Description | |||
| Chassis model | EQ2102 | ||
| Cab | Flat-roof, half row | ||
| Wheelbase | 3500+1250mm | ||
| Tire specification | 12.5R20 | ||
| Tire quantity | 6+1 units | ||
| Engine | Engine model | EQB190 20 | |
| Emission level | Euro 2 | ||
| Displacement/output | 6700ml/140kw | ||
| Horse power | 190hp | ||
| Gear box | Type | 6MT | |
| Number of gears | 6 forward gears& 1 reverse | ||
| Brake system | Full air brake system | ||
| Axle | Front | 4T- Elliot type, I beam section | |
| Rear | 4.4T*2 | ||
| Suspension | Front | 7- Leaf spring with shock absorber | |
| Rear | 9+6-Leaf spring | ||
| Fuel tanker | Type | Steel fuel tank, with lockable cap | |
| Capacity | 160L | ||
| Up-part description | |||
| Tanker | Capacity | 10cbm | |
| Material | Carbon steel | ||
| Thickness | 5mm | ||
| Standard configuration | Equipped with 2 sets manhole . | ||
| Equipped with double discharge valve and valve box. | |||
| Equipped with refueling dispenser, flow meter. | |||
| Equipped with surge baffles, ladder, roof coaming, skid resistant walkway, and toolbox. | |||
| Equipped with electrostatic conducting tape and double fire extinguishers. | |||
| Optional configuration | 1. Tanker material: aluminum alloy; stainless steel | ||
| 2. Chinese standard configuration is available, or other world famous fuel configuration. | |||
| 3. The whole set of European configurations for each compartment: European type manhole,over flow probe system, vapor recovery | |||
| system, bottom valve, API adaptors. | |||
| 4. Emergency bottom valve and foldable aluminum handrail. | |||
| 5. Others: fuel pump, refueling dispenser, flow meter, dipstick, etc. | |||
Optional configuration
1. Tanker material: aluminum alloy; stainless steel
2. Chinese standard configuration is available, or other world famous fuel configuration.
3. The whole set of European configurations for each compartment: European type manhole,over flow probe system, vapor recovery
system, bottom valve, API adaptors.
The Most Powerful Factory in China
Established in 1982; Total assets of 70 million dollars; Factory covers an area of 400,000 square meters; Strong semi-trailer factory in China; One of the drafters of China's semi-trailer standard.
China's Export Is Far Ahead
Sinotruk Truck Supporting Manufacturer Export more than 10,000 semi-trailers per year; Exporting more than 5,000 tanker trucks per year; More than 50 invention patents More than 200 utility model patents
