2 Axle Low Bed Semi Trailer for Sale Price

Description

2 Axle Low Bed Semi Trailer Advantages:

1, Truck trailer for carry excavator, loader, bulldozer and other heavy machinery
2, 30T loading capacity，size:10*2.5m, 900mm loading deck height
3, Customization is acceptable for ,loading capacity ,size and style
4, China leading semi trailer manufacturer since 1982, export business start from 2006
5, With more than 400 welders to make sure delivery on time

2 Axle Low Bed Semi Trailer Specification:

Weight:	Tare Weight	8T
	Loading capacity	30 T
	Total weight	61.5 T
Dimensions:	Outside dimension	1000025001550 mm (The final dimensions depend on the final design drawings)
Frame:	Design/welding technology	Heavy duty and extra durability designed;welding by automatic Submerged-Arc processes.
	Main beam	Opting for high strength Q345B steel, 500mm deep welded I-section main beams Top Flange thickness 16mm, width 140mm; Bottom Flange thickness 18mm, width 140mm.Middle Flange thickness 10mm;
	Cross beam	Heavy duty Special U steel
	Side beam	200mm high I beam
	Floor	4 mm thickness chequer plate
	Rear ladder (ramps)	Without
OEM parts:	Axle	2 *11.5T capacity, FUWA brand (Chinese best brand)
	King Pin	2.00’’/3.5’’ bolting king pin, JOST brand
	Suspension	Heavy duty undermount suspension with equalizers, American design (high-strength type)
	Steel Spring	10pcs leaf spring, 13mm thickness, 90mm width
	Landing legs	JOST brand, manual operation landing legs with sand shoe
	Tire specs	8.25R15, Triangle brand (Chinese famous brand)
	Rim	6.5(Chinese famous brand)
	Number of wheel	9pieces(including one spare wheel)
	Brake system	WABCO relay valve; Four double and two single brake chamber; Two units of ISO standard coppery air-connector.
	ABS system	Without（Can be choose freely,450 USD/set）
	Electrical:	One unit of 24V 7-pin ISO 1185 socket; LED lights
Miscellaneous:	Painting	color advised by client
	Marking	Standard
	Side Guard	Standard
	Spare Tire Carriers	Two set of heavy duty spare wheel carriers
	Tools box	One piece (1. 00. 50. 5m), under the goose neck(with 1 Tire spanner,1 gudgeon sleeve and 1 cranking bar)
Note: All the details not mentioned will design as the final confirmation with the customer

2 Axle Semi Low Bed Trailer

Our engineers will design the trailer main beam chassis depend on the load capacity that provided by the end user customer, and we have 2 axle 3 axle low bed trailer, we choose Q345B high tensile steel in an thicken thickness, with automatic Submerged-Arc welding processes, to make sure the low bed trailer with an strong loading deck.

2 Axle Lowbed Trailer Semi Trailer

The reliability of a product is considered as a most important quality of the product, we choose the top brand of the spare parts that we can get like BPW, JOST, WABCO,FUWA....To make sure the low bed trailer with an good reliability of the quality.

The Most Powerful Factory in China

Established in 1982; Total assets of 70 million dollars; Factory covers an area of 400,000 square meters; Strong semi-trailer factory in China; One of the drafters of China's semi-trailer standard.

We have our own production workshop

We have our own production workshop with short production cycle and will deliver to you in the shortest time.
