4 Axle 100 Ton Tipper Semi Trailer
Dump trailer allows goods to be unloaded from the side. The main types of cargo transported by this semi-trailer are building materials, such as stone, sand, etc.
Description
semi dump trailers advantages:
1. High loading and unloading efficiency, can complete the unloading in a short period of time, greatly improving the loading and unloading efficiency;
2. Clean unloading, can reduce the goods in the transportation and loading and unloading links of the residence time, improve the transportation turnover rate;
3. Low transportation cost, reducing the workers’ loading and unloading links, reducing the labor cost investment.
semi dump trailers specification:
| Main Dimension | |
| Manufacturer: | TONGYA AUTOMOBILE.CO.,LTD |
| Place of Origin： | Shandong, China |
| Type： | Dump Truck Semi Trailer |
| Dimension: | 10500*2550*3700mm (can be customized) |
| Tare Weight: | About 12-15T (12.62T) |
| Loading Capacity: | ≤60T |
| Side Wall Thickness(mm): | 5mm 450 Wear-resistant steel |
| Bottom Plate Thickness(mm): | 6mm 450 Wear-resistant steel |
| Chassis | |
| Main Beam: | Material Q355D Steel |
| Height::500mm | |
| Upper plate:16mm | |
| Middle plate:10mm | |
| Down plate:18mm | |
| King Pin: | JOST brand 3.5 inch |
| Support Legs： | JOST brand A300C |
| Axle: | 13T*4, FUWA Brand (Chinese famous brand) |
| Suspension: | Mechanical suspension |
| Spring Leaf: | 90(width)mm*13(thickness)mm*10layer |
| Lifting System: | Georg brand GFC200-5-07200-K0486 |
| Tire: | 12R22.5*17 Triangle brand ( various tire brands are available) |
| Rim: | 9.0-22.5*17 |
| ABS: | WABCO |
| Emergency Brake Valve: | WABCO |
| Spare Tire: | 1 Piece |
| Painting: | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Accessories: | One standard tool box |
4 Axle 60 Cubic Tipper Semi Trailer
Dump trailer can be used in many other fields such as construction, agriculture, etc. The load capacity of the side tipper trailer may be greater than that of the rear tractor tipper trailer.
The Most Powerful Factory in China
Established in 1982; Total assets of 70 million dollars; Factory covers an area of 400,000 square meters; Strong semi-trailer factory in China; One of the drafters of China's semi-trailer standard.
We have our own production workshop
Our company covers an area of 400,000 square meters, total assets 7million US dollar. There are 156 persons with senior technical title. four-wheel ATD-GPS and 1200 sets TEST EQUIPMENT which are advanced technology and Hi-Tech equipment.
