3 Axle 40 Cubic Tipper Semi Trailer for Sale In Cameroon

Description

Side Dump Semi Trailer of Advantages:

1、Working for mines or other large projects, mainly transport gravel, soil and coal,
2、Available for customization: including color and tire specifications, axles and dimension,
3、High efficiency: the side tipping semi-trailer is more efficiently for quick and easy loading and unloading of materials,
4、Excellent technology: the main components are processed by advanced equipment, the longitudinal beam is made by automatic submerged arc welding, and the assembly machine is used to accurately assemble the axle and leaf spring.

Side Dump Semi Trailer of Specification:

Specification
Outside Dimension	12500mm2500mm2500mm(the final dimension is according the final drawing picture)
Tare weight	About 9.3tons
Axle	3 axles, TONGYADA brand 13tons per axles
Loading capacity	40tons
Side wall thickness	2mm
Bottom platform	3mm smooth platform
Lifting system	E1104pcs + E1202pcs lifting cylinder, 1 shifting cylinder , PTO
Side beam	16# channel steel
Main beam(q345)	Height: 500mm, upper plate is 14mm, middle is 8mm,down plate is 16mm
Landing gear	Jost A300C or standard 28 tons
King Pin	Jost 2.0 or 3.5 inch bolt-in type
Suspension	Mechanical suspension America type
Leaf spring	90(W)mm13(thickness)10 Layer
Pneumatic Braking System	WABCO RE 6 relay valve; spring brake chamber; one piece of 45L air tanks
Rim	9.0*22.5 brand can be optional 12pcs
Tire	12R222.5 brand can be optional 12pcs
ABS	optional
Painting	Spray powder
Accessories	One standard tool box(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)One spare tire carrier24 weld on winchRope hook

For more details,please contact us.We will offer you the most competitive pricing.
