Shacman X5000 Tractor Truck

Description

Shacman X5000 6×4 Tractor Head
Drive type	6×4
Weight	Gross Vehicle Weight	≤50
Dimensions	Wheelbase/(mm)	3175+1400
Performance	Maximum speed/(km/h)	45～60/90
Performance	Ground clearance	>314
Engine	Brand	WEICHAI
	Model	WP12.460E50
	Power/(kw/HP)	338kw / 460Hp
	Maximum torque / (N.M)/rpm	2110 N·M
	Displacement/(L)	12.596 L
	Emission standard	Euro V
Gear box	Brand	FAST
Gear box	Model	12JSD200T-B
Clutch	Type	φ430 Diaphragm spring clutch
Cooling	Type	Domestic heat sink
Air inlet	Type	Ordinary air filter
Brakes	Type	Drum brake
	Service brake	Double circuit air brake
	Park brake	Rear wheel spring brake
	Auxiliary brake	WEVB engine exhaust brake
Steering	Type	ZF8098 technology, circulating ball steering machine
Chassis	Type	Parallel trapezoidal frame with variable section
Chassis	Dimensions/(mm)	(940-850)X300(single 8)
Suspension	Front	Multi-layered leaf springs
Suspension	Rear	Multi-layered leaf springs
Axles	Brand	HANDE
	Front axle	7.5T front axle MAN technology
	Rear axle	13T MAN Double Reduction Drive axle with inter helix differential and differential lock, bridge speed ratio: 4.769
Tires	Type	12R22.5
Fuel tank	Tank capacity/(L)	400L Aluminum tank
Electrics	Type	24V
Electrics	Battery	165Ah Maintenance-free battery
Cab	Type	SHACMAN X5000 Extended High Roof cab
Cab	Equipment	Air main seat, four-point air-suspended cab, electronically controlled automatic temperature-controlled air conditioning, electric window rollers, manual flip, telescopic axle maneuvering, regular 50 saddle, split fenders, 165Ah maintenance-free battery, SHACMAN logo, full English logo.

Product Images

The X5000 series delivers on all fronts. It features a powerful and efficient engine, a comfortable and ergonomic cab, and a comprehensive maintenance service for the entire vehicle and its components. No matter what your business requires, the X5000 series can adapt to your specific needs.

Power to meet demands

Powered by WEICHAI & CUMMINS engines, FAST transmission, HANDE axle. The customized powertrain is developed to utilize 11L-13L engine displacement, 345-560 horsepower, 2550n.m max output torque, while complying with Euro II, V or VI emission standards.

Less fuel, more road

The X5000 series achieves optimal fuel efficiency, thanks to the FAST transmission, 12-gear direct clutch, and dual intermediate shaft design. These features ensure smooth and easy gear shifting, and minimize power loss during transmission.

Driver focused

The X5000 series is designed to provide comfort and convenience for the drivers, so they can concentrate on their work. It features a maneuverable chassis, a spacious cab with a clear view, and a user-friendly powertrain that reduces driving fatigue.

Partner on the road

The X5000 series offers a superior driving experience, with its car-like interiors, pneumatic operated seats, panoramic windshield, and surrounding dashboard. It also features a four-point air suspension system and a transverse shock absorber that provide comfort and stability on any road condition.

Safety first

Safety is our top priority for every vehicle user. The X5000 features a comprehensive active and passive safety system that protects both drivers and those around them. Imagine driving on the road with minimal distractions and maximum comfort, reaching your destination with ease. That is the peace of mind we offer with the X5000.
